Tus neeg xyuas pib: Plain annealed tooj liab tus neeg xyuas pib rau AS / NZS 1125
-
Rwb thaiv tsev: V-90 PVC
-
Rwb thaiv tsev xim: Liab, Dub
-
Lub cev: 5V -90 PVC
-
Ua haujlwm kub li qub: +75 degree
-
Yam tsawg kawg nkaus ua haujlwm kub: -15 degree
-
Txuj: AS/NZS 5000.2.
-
Lub hwj chim: 450/750V
Daim ntawv thov
Ob chav insulated ib leeg tub ntxhais cable feem ntau yog siv rau ntau yam kev siv uas muaj kev nyab xeeb, kev ntseeg siab, thiab kev tiv thaiv hluav taws xob tseem ceeb heev. Tshwj xeeb tshaj yog, nws yog qhov zoo tagnrho rau cov mains, submains, thiab subcircuits uas tsis tau kaw, kaw rau hauv cov kav dej, faus, lossis ntsia hauv cov ducts hauv av, tshwj xeeb tshaj yog nyob rau hauv cov tsev thiab cov nroj tsuag. Cov kev teeb tsa no feem ntau nyob rau hauv ib puag ncig uas cov cables tsis raug kev puas tsuaj rau cov khoom siv, vim tias ob chav rwb thaiv tsev muab ib txheej ntxiv ntawm kev tiv thaiv, ua kom muaj kev ruaj ntseg hluav taws xob.
Feature
450/750V ob chav insulated ib tug tub ntxhais cable nta ib qho yooj yim annealed tooj liab neeg xyuas pib ua raws li AS / NZS 1125, uas muab zoo heev hluav taws xob conductivity. Tus neeg xyuas pib tuaj yeem ua haujlwm ntawm qhov kub txog li 90 degree raws li AS / NZS 3008.1, yog tias nws tsis tuaj yeem hloov kho. Lub cable yog insulated nrog V-90 PVC, uas muab hluav taws xob rwb thaiv tsev zoo thiab muaj zog tiv thaiv kev puas tsuaj, ya raws thiab ib puag ncig yam. Tsis tas li ntawd, lub tsho yog ua los ntawm V-90 PVC, muab kev tiv thaiv zoo thaum ua kom muaj kev ywj pheej thiab yooj yim ntawm kev tuav thaum lub sijhawm teeb tsa. Nrog rau qhov kub thiab txias ua haujlwm ntawm +75 degree thiab qhov ntsuas kub tsawg kawg ntawm -15 degree, lub cable no muaj ntau yam thiab tsim nyog rau ntau yam kev siv.
Daim ntawv pov thawj
Peb cov khoom tau dhau UL, SAA, TUV, VDE, CE, CB thiab lwm yam ntawv pov thawj. Peb lub tuam txhab muaj cov ntawv pov thawj zoo rau txhua cheeb tsam. Peb muaj ntau tshaj li 10 xyoo ntawm kev paub nyob rau hauv kev lag luam tawm txawv teb chaws, exporting rau ntau tshaj 90 lub teb chaws nyob ib ncig ntawm lub ntiaj teb no, thiab paub txog cov hlau thiab cable specifications thiab cov qauv ntawm ntau lub teb chaws.
Pob
Hoobkas
Dongguan Greater Wire & Cable Co., Ltd. yog tsim nyob rau hauv 1995, nws yog ib tug kws tshaj lij hlau thiab cable chaw tsim tshuaj paus. Peb lub tuam txhab muaj cov cuab yeej siv ntau lawm thiab cov cuab yeej tsim khoom, ua tiav cov khoom siv, thiab cov khoom siv tshuab muaj zog. Tom qab xyoo ntawm kev ua haujlwm hnyav thiab kev txhawb nqa ntawm cov neeg siv khoom los ntawm thoob plaws lub ntiaj teb, peb lub tuam txhab tau tsim kho sai thiab yeej muaj kev hwm thiab koom nrog kev lag luam txawv teb chaws. Lub tuam txhab tau dhau ls09001 kev tswj hwm kev ua haujlwm tau ntawv pov thawj, National high tech enterprise certification, national specialization, and special new enterprise certification.
Case
Tus khub
FAQ
Q: Koj puas yog cov chaw tsim khoom lossis tuam txhab lag luam?
Q: Koj qhov Kev Txiav Txim Tsawg kawg yog dab tsi?
Cim npe nrov: 450/750v ob chav insulated ib core cable, Tuam Tshoj 450/750v ob chav insulated ib tub ntxhais cable manufacturers, lwm tus neeg, Hoobkas
| Tus coj | Kab | Min ntsia khoov vojvoog mm |
|||||
|
Nominal CSA mm |
Tus naj npawb thiab txoj kab uas hla ntawm cov xov hlau Tsis muaj / mm |
Number diam mm | Nominal rwb thaiv tsev thickness mm |
Zuag qhia tag nrho | Kwv yees li. hnyav kg/100 m | ||
| Yam tsawg kawg nkaus mm | Qhov siab tshaj plaws mm | ||||||
| 1.0 | 7/0.42 | 1.26 | 0.6 | 3.9 | 4.1 | 2.9 | 15 |
| 1.5 | 7/0.52 | 1.56 | 0.6 | 4.3 | 4.5 | 3.5 | 20 |
| 2.5 | 7/0.67 | 2.0 | 0.7 | 5.0 | 5.2 | 5.1 | 20 |
| 4 | 7/0.85 | 2.6 | 0.8 | 6.0 | 6.2 | 7.4 | 25 |
| 6 | 7/1.04 | 3.1 | 0.8 | 6.5 | 6.7 | 10 | 25 |
| 10 | 7/1.35 | 4.1 | 1.0 | 7.8 | 8.2 | 15 | 35 |
| 16 | 7/1.70 | 5.1 | 1.0 | 9.1 | 9.4 | 22 | 40 |
