Kev xaiv hluav taws xob cable tsis yog tsuas yog hais txog qhov ntsuas hluav taws xob thiab tus neeg xyuas pib loj - ib puag ncig ua lub luag haujlwm tseem ceeb. Nrog kev siv ntau ntxivAustralian tus qauv 110℃cablesNyob rau hauv niaj hnub infrastructure, ib tug nquag nug tshwm sim:
Cov kab no puas tuaj yeem siv tau zoo nyob rau sab nraum zoov lossis qhov chaw ntub dej?Kab lus no teb tias los ntawm kev piav qhia tias cov cables no yog dab tsi, lawv tsim ua li cas, thiab qhov chaw ib puag ncig lawv tuaj yeem tiv taus.
Kev ua tau zoo thiab cov qauv ntawmAustralian tus qauv 110℃hluav taws xob xaim
Australian 110℃hluav taws xob cables, feem ntau hu uaelastomer cables, yog tsim tshwj xeeb uas tsis tshua muaj -voltage cables uas tuaj yeem ua haujlwm ntawm qhov kub txog li 110℃. Cov no yogelastomer insulated cablesfeaturing:
Class 5 hloov tau tooj liab conductorsrau zoo conductivity thiab yooj
X-HF-110 elastomer rwb thaiv tsev- tus pas ntsuas kub, qis- pa luam yeeb, halogen- khoom siv dawb
HFS-110-TP tsis tshua muaj pa luam yeeb zero halogen (LSZH) txheej txheejrau kev tiv thaiv ib puag ncig
Cov kab hluav taws xob zoo li no feem ntau siv rau hauv cov kab hluav taws xob ruaj khov uas yuav tsum tau ua kom muaj cua sov thiab txhim kho kev nyab xeeb.
Rated voltage:0.6/1 kV
Ua haujlwm temp:-40℃rau +110 degree
Luv -Circuit Temp:mus txog 250℃rau lub sijhawm luv
Cov khoom nta muaj feem xyuam rau Environmental Exposure X-HF-110 Elastomer Rwb thaiv tsev
CovX-HF-110 rwb thaiv tsevyog tus ntoo khaub lig-linked thermoset polymer uas muab:
Siabthermal endurance, tso cai rau kev ua haujlwm tas mus li 110 degree
Cov pa luam yeeb tsawg thiab halogen- tus cwj pwm tsis pub muaj kev nyab xeeb thaum hluav taws
Kev ua haujlwm ruaj khov ntawm dielectric resistant rau tshav kub- laus thiab ib puag ncig hnav
Vim tias cov yam ntxwv no, elastomer rwb thaiv tsev ua tau zoo dua li cov qauv PVC hauv cov xwm txheej hnyav, suav nroghigh humidity los yog damp nyob rau hauv qhov chaw.
HFS-110-TP txheej txheej
CovHFS-110-TPsheath yog ib qho qis- pa taws, halogen- pub dawb thermoset compound tsim los sib npaug:
Basic mechanical tiv thaiv(Abrasion kuj, chemical resistance)
Cov pa luam yeeb tsawghauv hluav taws
Kev ua tau zoo nyob rau hauv ib puag ncig nrog kev ya raws, dej txaws, thiab huab cua huab cua
Txawm li cas los xij, HFS-110-TP sheath yogfeem ntau tsis yog hnyav - lub tsho sab nraum zoovxws li tshwj xeeb UV- tiv taus lossis ntub- qhov chaw ntsuas cov ntaub qhwv.
Txais sab nraum zoov lossis damp
Seb ibAustralian 110℃cableyog haum rau sab nraum zoov los yog damp daim ntaub ntawv nyob ntawm tustej yam kev mobthiab covqib kev tiv thaiv muabes tsis yog qhov ntsuas kub ib leeg. Hauv qab no yog cov xwm txheej uas cov cables tuaj yeem siv tau zoo:
Sab nraum zoov nrog kev tiv thaiv
Yog hais tias lub cable yog routed sab nraum tab sistiv thaiv los ntawm cov kav dej, cov tais, lossis cov kav dej, nws tuaj yeem ua haujlwm ntseeg tau:
Nyob rau hauv lub ru tsev overhangs los yog nyob rau hauv kev pab cuam corridors
Sab hauv cov kav dej nrog cov dej tso tawm
Nyob rau hauv cov tais cable uas tiv thaiv los ntawm nag lossis hnub
Nyob rau hauv tas li ntawd, cov ntaub ntawv elastomer muab txaus noo noo tsis kam thiab kub robustnesstsuav yog qhov raug raug txo kom tsawg.
Damp Sab Hauv Tsev lossis Semi- Ib puag ncig sab nraum zoov
Australian 110℃cablestuaj yeem ua tau zoo hauv:
Warehouses, industrial halls, thiab cov khoom siv chav nrog av noo
Nyob ze ntawm cov cua tuav los yog cov tshuab cua txias uas muaj qhov sib xyaw ua ke
Hluav taws xob tswj vaj huam sib luag nyob rau hauv ib nrab- chaw ntub dej
Lub elastomer rwb thaiv tsev thiab LSZH sheath tswj txhua yam thiab hluav taws xob stability nyob rau hauv cov mob no.
Kev txwv rau kev siv sab nraum zoov lossis damp
Thaum Australian 110℃cables muaj zog nyob rau hauv ntau qhov chaw, muaj cov xwm txheej uas lawvyuav tsum tsis txhob siv yam tsis muaj kev tiv thaiv ntxiv:
Los nag ncaj qha thiab UV raug
Lub cable lub sheath tsis inherently muab:
UV tsis kamrau lub sij hawm ntev - raug tshav ntuj
Kev tiv thaiv dej ingressrau sustained rainfall contact
Sheath cov ntaub ntawv zoo li HFS-110-TP tsis tau teev tias yog UV-stabilized los yog tsis muaj dej los ntawm lub neej ntawd
Rau kev khiav tawm sab nraum zoov raug tshav ntuj thiab nag tsis muaj cov kav dej lossis cov tais, kev tiv thaiv ntxiv yog tsim nyog.
Submerged los yog Splashed Water conditions
Txawm hais tias X-HF-110 rwb thaiv tsev thiab HFS-110-TP sheath tiv taus ya raws, lawv yogtsis yog tsim los rau lub caij nyoog immersion. Kev sib cuag ncaj qha nrog cov dej sawv ntsug, dej nyab, lossis cov voj voog ntub dej tsis tu ncua tuaj yeem cuam tshuam kev ncaj ncees ntawm lub sijhawm tshwj tsis yog:
Cable yog muab tso rau hauv ib lub duct kaw
Cable yog khiav hauv cov ntaub thaiv dej tsis zoo
Underground lossis Direct Burial
Australian 110℃cablestsis tau teev tseg raws li ncaj qha - faus rated. Thaum cov khoom uas muaj elastomer rwb thaiv tsev tuaj yeem tiv taus ya raws, kev sib cuag hauv ntiaj teb ncaj qha yuav tsum raug zam yam tsis muaj cov kav dej tiv thaiv lossis tsim nyog hauv av- cov hom cable.
Engineering Considerations rau Tsim thiab Installation
Thaum ntsuam xyuas yog Australian 110℃cable haum rau ib qho chaw sab nraum zoov lossis chaw ntub dej, xav txog cov hauv qab no engineering:
Txoj Kev Txhim Kho
Kev siv sab nraum zoovhauv cov kav dej los yog cov taisnce durability ntau
Qhib-air suspended installation yuav ua rau cov ntaub thaiv UV thiab los nag
Environmental Stress
Kub viav vias, cua- cua los nag, thiab plua plav tuaj yeem ua rau cov ntaub thaiv tsis muaj kev tiv thaiv
Cov ntaub thaiv npog thiab thaj chaw muaj kev lag luam nrog cov dej txaws txawv ntawm qhov tseeb sab nraum zoov
Kev ua raws li qhov project
Cov phiaj xwm yuav tsum ua raws li cov qauv Australian thiab New Zealand (AS/NZS 5000.1, AS/NZS 3808), tshwj xeeb tshaj yog rau kev nyab xeeb hluav taws thiab cov pa luam yeeb tsawg. Elastomer cables zoo liX-HF-110 cableyog SAA tau ntawv pov thawj, ua kom muaj kev ua raws li kev teeb tsa ruaj khov nrog kev tswj hwm ib puag ncig.
Kev coj ua zoo tshaj plaws rau kev teeb tsa sab nraum zoov / damp
Txhawm rau kom ntseeg tau ntev -lub sij hawm kev ntseeg siab ntawm Australian 110℃cables nyob rau sab nraum zoov lossis chaw ntub dej:
Siv Mechanical Protection
Nruab rau hauv cov kav dej los yog cable tais nrog npog
Tsis txhob raug tshav ntuj ncaj qha thiab los nag
Muab cov dej ntws los yog tswj cov dej noo hauv cov kab trench
Ntxiv UV-Resistant Outer Layer
Yog tias qhov tshwm sim sab nraum zoov tsis tuaj yeem zam tau, xav txog ntxiv aUV- tiv thaiv lub tsho sab nrauvlos yog lub tes tsho tiv thaiv.
Tsis txhob faus ncaj qha lossis submersion
Rau kev teeb tsa hauv av, siv cov cables tshwj xeeb rau kev faus ncaj qha lossis ua kom tag nrho cov kab hauv cov dej noo- pov thawj.
Haum tab sis nrog kev txwv
Australian tus qauv 110℃cables, tshwj xeebelastomer kabtsim nrogX-HF-110 rwb thaiv tsevthiabHFS-110-TP sheath, yogmuaj peev xwm ua haujlwm hauv qhov chaw ntub dej thiab qee qhov chaw nyob sab nraum zoov.
Lawvcov khoom sivmuab zoo noo noo tsis kam thiab kub endurance.
Txawm li cas los xij, lawvtsis yog sab nraum zoov - ntsuasrau cov nag ncaj qha, tiv thaiv dej tsis tu ncua, hluav taws xob UV, lossis kev faus ncaj qha tshwj tsis yog muaj kev tiv thaiv nrog cov kav dej lossis cov txheej tiv thaiv ntxiv.
Nrog rau txoj kev txhim kho kom raug thiab kev tswj ib puag ncig, cov cables no tuaj yeem siv tau zoo hauv cov haujlwm uas cuam tshuam rau sab nraum zoov lossis ntub dej - tab sisqhov ntsuas kub ib leeg tsis yog qhov lavrau kev siv sab nraum zoov ncaj qha.
