Hauv cov tshuab hluav taws xob, TPS cable (thermoplastic sheathed cable) yog ib qho ntawm cov kab hluav taws xob ntau thiab siv dav. Nws cov ntaub qhwv sab nrauv yog ua los ntawm cov ntaub ntawv thermoplastic (xws li polyvinyl chloride), uas ua rau cov cable muaj kev cuam tshuam zoo heev, tiv thaiv corrosion thiab ya raws, yog li nws tuaj yeem muab kev sib kis tau zoo hauv ntau qhov chaw. Tshwj xeeb tshaj yog rau tsev, kev lag luam thiab kev lag luam hluav taws xob thaiv, TPS cable yog dav siv vim nws cov kev ua tau zoo tshaj. Ntawm lawv, 2.5 hli 2C E TPS cable yog qhov tseem ceeb tshwj xeeb hauv ntau yam kev siv hluav taws xob vim nws cov qauv siv hluav taws xob dual thiab muaj peev xwm nqa tam sim no.
Nyob rau hauv tsab xov xwm no, peb yuav tham txog cov yam ntxwv, kev ua hauj lwm hauv paus ntsiab lus, Scope ntawm kev siv 2.5 hli 2C E TPS cable thiab nws kev sib piv nrog rau lwm yam cable specifications xws li 1.5 hli TPS cable thiab TPS 2.5 hli cable.
1. 2.5 hli 2C E TPS cable yog dab tsi?
2.5 hli 2C E TPS cable yog ib tug cable specification nrog ob conductors, qhov twg "2.5 hli" txhais tau tias lub cross-sectional cheeb tsam ntawm cov hlau yog 2.5 square millimeters, 2C txhais tau tias muaj ob conductors (nyob conductors) nyob rau hauv lub cable, thiab E feem ntau txhais tau hais tias lub cable ua tau raws li cov qauv kev nyab xeeb hluav taws xob cuam tshuam thiab tsim nyog rau tsev neeg zoo tib yam lossis kev lag luam hluav taws xob. TPS txhais tau hais tias lub cable siv cov khoom siv thermoplastics (xws li polyvinyl chloride PVC) ua cov txheej txheej los xyuas kom meej tias nws muaj cov khoom siv zoo heev thiab kev tiv thaiv kev ua haujlwm.
2. Cov qauv ntawm 2.5 hli 2C E TPS cable
2.5 hli 2C E TPS cable feem ntau yog tsim los ntawm cov hauv qab no lub ntsiab:
2.1 Tus coj
Tus neeg xyuas pib hauv lub cable feem ntau yog ua los ntawm tooj liab lossis txhuas hlau, thiab qhov loj ntawm tus neeg xyuas pib yog 2.5 square millimeters, uas txhais tau hais tias txhua tus neeg xyuas pib tuaj yeem nqa cov tam sim no loj, feem ntau tsim nyog rau lub sijhawm tam sim no ntawm 16 amps txog 20 amps.
2.2 rwb thaiv tsev txheej
Txhua tus neeg xyuas pib muaj txheej txheej rwb thaiv tsev sab nraud, feem ntau yog ua los ntawm PVC lossis cov ntaub ntawv zoo sib xws, kom ntseeg tau tias tam sim no tsis xau thiab tsis txhob cuam tshuam nrog cov khoom siv sab nraud. Cov txheej insulating no muaj cov cua kub zoo, tiv thaiv corrosion thiab UV tsis kam.
2.3 Cov
Sab nrauv ntawm lub cable kuj yog ua los ntawm cov khoom siv thermoplastic, feem ntau yog PVC, uas muaj lub zog zoo heev thiab tuaj yeem tiv thaiv lub cev puas tsuaj los ntawm sab nraud. Nws tseem yog dej tsis qab, noo noo-pov thawj thiab UV-resistant, haum rau siv nyob rau hauv ntau qhov chaw.
3. Nta ntawm 2.5 hli 2C E TPS Cable
2.5 hli 2C E TPS cable muaj cov yam ntxwv tshwj xeeb hauv qab no, ua rau nws tsim nyog rau ntau yam kev siv hluav taws xob:
3.1 Loj tam sim no nqa peev xwm
Tus neeg xyuas pib hla thaj tsam ntawm 2.5 hli 2C E TPS cable yog 2.5 square millimeters, yog li nws tuaj yeem nqa cov khoom loj tam sim no thiab feem ntau haum rau kev xa tawm tam sim no ntawm 16 amps mus rau 20 amps. Nws tuaj yeem ua tau raws li lub zog xav tau ntawm ntau qhov nruab nrab thiab cov khoom siv hluav taws xob siab, xws li cua txias, hluav taws xob cua sov thiab lwm yam khoom siv hluav taws xob hauv tsev.
3.2 Dual-conductor tsim
Lub 2.5 hli 2C E TPS cable muaj ib tug dual-conductor qauv thiab yog feem ntau haum rau daim ntaub ntawv uas yuav tsum tau ob tug nyob circuits. Piv txwv li, cov kab hluav taws xob no tuaj yeem siv nyob rau hauv ib qho kev tswj xyuas dual-tswj Circuit Court, lossis qee lub sijhawm uas yuav tsum muaj lub zog ywj pheej, lub zog ntawm ob lub voj voog tuaj yeem pom tau los ntawm ob lub xov tooj ywj pheej.
3.3 Zoo heev durability
Lub cable txais yuav cov thermoplastic sheath, uas tuaj yeem tiv taus qee qhov kev puas tsuaj ntawm cov khoom siv, tsis muaj dej tsis zoo thiab tsis muaj dej, thiab tsim nyog rau ntau qhov chaw hnyav. Nws kuj tseem tiv taus UV hluav taws xob, yog li nws tsim nyog rau lub sijhawm ntev rau qhov chaw sab nraum zoov.
3.4 Wide adaptability
2.5 hli 2C E TPS cable yog tsim rau ntau yam kev siv hluav taws xob, tshwj xeeb tshaj yog nyob rau hauv ib puag ncig uas yuav tsum tau muaj ob lub conductors los yog dual tswj. Vim nws zoo heev kub tsis kam thiab durability, nws yuav siv tau rau lub sij hawm ntev nyob rau hauv ntau yam kub thiab tej yam kev mob.
4. Scope ntawm kev siv 2.5 hli 2C E TPS cable
2.5 hli 2C E TPS cable yog dav siv hauv tsev hluav taws xob, cov tsev lag luam, kev lag luam tswj thiab hluav taws xob thaiv hauv qee qhov chaw tshwj xeeb. Cov hauv qab no yog nws lub sijhawm siv tseem ceeb:
4.1 Dual-tswj hloov Circuit Court
Hauv cov tsev thiab cov tsev lag luam, 2.5 hli 2C E TPS cables tuaj yeem siv rau hauv ob lub tshuab hluav taws xob hloov hluav taws xob, uas yog, cov khoom siv tib yam (xws li teeb, kiv cua, thiab lwm yam) yog tswj los ntawm ob qhov sib txawv. Kev tsim dual-tus neeg xyuas pib ntawm lub cable no yog qhov tsim nyog rau kev txuas ob lub keyboards thiab ib qho khoom siv hluav taws xob, ua rau kev tswj xyuas hluav taws xob hloov tau yooj yim.
Piv txwv li, ob lub tshuab hluav taws xob tau nruab rau hauv ib chav, ib qho tswj cov teeb pom kev zoo hauv chav, thiab lwm yam tswj qhov qhib thiab kaw ntawm tib lub teeb pom kev zoo. Los ntawm kev siv 2.5 hli 2C E TPS cables, nws yog ib qho yooj yim los txuas ob lub keyboards mus rau lub teeb pom kev zoo kom ntseeg tau tias ob txoj kev tswj tau zoo.
4.2 Multi-circuit fais fab mov system
Hauv qee qhov kev siv hluav taws xob, nws yog ib qho tsim nyog los muab cov khoom siv hluav taws xob ywj pheej rau cov khoom siv hluav taws xob sib txawv. Lub sijhawm no, tus neeg xyuas pib dual tus qauv tsim ntawm 2.5 mm 2C E TPS cables tuaj yeem txhawb nqa lub zog ywj pheej ntawm ntau lub voj voog thiab zam kev cuam tshuam tam sim no thiab kev sib tw ntawm ntau lub voj voog.
Piv txwv li, nyob rau hauv ib puag ncig xws li chav ua noj lossis chav dej, tej zaum yuav tsim nyog los muab cov khoom siv hluav taws xob sib cais rau cov khoom siv hluav taws xob xws li hluav taws xob cua sov, tub yees, thiab microwave ncu. Cov khoom siv no feem ntau xav tau kev ywj pheej circuits, thiab 2.5 hli 2C E TPS cables tuaj yeem muab kev sib txuas hluav taws xob hloov tau rau ntau lub voj voog.
4.3 Fais fab mov rau nruab nrab thiab siab zog li
Vim tias 2.5 hli 2C E TPS cables tuaj yeem nqa cov dej ntws loj, lawv tau siv dav hauv kev xa hluav taws xob rau cov khoom siv hluav taws xob nruab nrab thiab siab zog. Tshwj xeeb tshaj yog nyob rau hauv cov tsev, chaw ua hauj lwm, khw malls, thiab lwm yam., 2.5 hli 2C E TPS cables feem ntau yog siv rau lub hwj chim siab cov cuab yeej xws li cua txias, hluav taws xob cua sov dej, tub yees, thiab lwm yam.
4.4 Hluav taws xob thaiv hauv kev lag luam thiab kev lag luam ib puag ncig
Hauv cov tsev lag luam thiab cov chaw lag luam, 2.5 hli 2C E TPS cables tuaj yeem siv rau kev xa hluav taws xob, teeb pom kev zoo, kev tswj hwm, thiab lwm yam khoom siv hluav taws xob. Hauv cov cheeb tsam no, cov tshuab hluav taws xob feem ntau xav tau kev xa hluav taws xob siab, yog li nws yog ib qho tseem ceeb tshwj xeeb los xaiv cov kab hluav taws xob uas tuaj yeem nqa cov dej ntws loj.
4.5 Kev tsim hluav taws xob hauv tsev
Hauv cov tsev, tshwj xeeb tshaj yog nyob rau hauv cov tsev loj lossis cov tsev lag luam, 2.5 mm 2C E TPS cables tau dav siv rau kev xa hluav taws xob ntawm cov plag tsev. Cov cable no tuaj yeem xa cov hluav taws xob xav tau thiab txuas ntau yam khoom siv hluav taws xob thaum ua kom muaj kev nyab xeeb hluav taws xob thiab kev ua haujlwm zoo.
4.6 Hluav taws xob tswj thiab Automation Systems
Nyob rau hauv kev lag luam automation, 2.5 hli 2C E TPS cables yog siv rau hluav taws xob tswj systems, sensors, automation khoom thiab lawv cov kev twb kev txuas rau cov khoom siv fais fab. Txij li cov tshuab no feem ntau koom nrog ntau lub teeb liab hauv Circuit Court, 2.5 mm 2C E TPS cables tuaj yeem xa cov teeb liab sib txawv los tswj cov khoom siv los ntawm lawv cov yam ntxwv ntawm tus neeg xyuas pib dual.
5. Sib piv nrog lwm cov TPS cables
5.1 Sib piv nrog 1.5 hli TPS cables
Tam sim no nqa peev xwm:1.5 hli TPS cables muaj lub peev xwm nqa tam sim no qis dua, feem ntau 10 amps rau 13 amps, thiab tsim nyog rau cov khoom siv sib dua thiab cov khoom siv hluav taws xob. 2.5 hli 2C E TPS cables yog tsim rau cov khoom siv hluav taws xob ntau dua, thiab cov khoom nqa tam sim no feem ntau yog 16 amps txog 20 amps.
Daim ntawv thov:1.5 hli TPS cables feem ntau yog siv rau cov khoom siv hluav taws xob tsawg xws li cov teeb pom kev hauv tsev thiab cov khoom siv hluav taws xob tsawg, thaum 2.5 hli 2C E TPS cables yog tsim rau cov khoom siv nruab nrab thiab siab zog, ntau lub tshuab hluav taws xob, thiab ob lub tshuab hluav taws xob.
5.2 Sib piv nrog 2.5 hli TPS cables
Number ntawm conductors:2.5 hli TPS cables yog ib tug tub ntxhais cables, thaum 2.5 hli 2C E TPS cables muaj ib tug dual-conductor tsim. Lub tom kawg tuaj yeem txhawb nqa ob-tswj lossis ntau lub zog xa hluav taws xob, nrog kev hloov pauv ntau dua thiab hloov tau.
Scope ntawm kev siv:Txawm hais tias 2.5 hli TPS cables tsim nyog rau kev xa hluav taws xob yooj yim dua, 2.5 hli 2C E TPS cables tuaj yeem hloov mus rau ntau lub tshuab hluav taws xob, tshwj xeeb tshaj yog cov uas muaj ntau lub voj voog.
