- Conductors: 2C, 3C, 4C thiab 5C cores rau xaiv
- Ua haujlwm kub: -40 degree ~ 90 degree
- Max. Conductor Kub: 120 degree
- Rated voltage: 450/750V
- ConductorTinned tooj liab: 1.5mm² ~ 16mm²
- Rwb thaiv tsev: XLPE
- Jacket: XLPE, Xim dub
- Nplaim Test: IEC 60332-1
Daim ntawv thov
Tsim tshwj xeeb rau kev sib txuas hnub ci vaj huam sib luag rau AC lub zog, PV07AC-F hnub ci cable yog qhov tseem ceeb hauv lub hnub ci zog. Qhov zoo tshaj plaws rau ob qho tib si hauv tsev thiab kev lag luam hnub ci kev teeb tsa, nws muab kev txhim khu kev qha thiab muaj txiaj ntsig zoo rau AC lub zog, ua kom pom kev ua haujlwm zoo thiab siab tshaj plaws hloov hluav taws xob. Nws cov kev tsim kho zoo tau lees paub qhov ua haujlwm ntev thiab hloov tau yooj yim, tso cai rau nws tiv taus qhov hnyav sab nraum zoov thaum tswj kev ua haujlwm ntev. Txawm hais tias koj tab tom teeb tsa lub hnub ci tshiab lossis hloov kho ib qho uas twb muaj lawm, PV07AC-F cable tau ua tib zoo tsim los ua kom tau raws li cov kev xav tau tshwj xeeb ntawm kev siv hnub ci, ua kom muaj kev nyab xeeb, tsis muaj zog hloov mus rau ntau xyoo tom ntej.
Feature
PV07AC-F hnub ci AC cable yog cov kev ua tau zoo tshaj plaws tsim tshwj xeeb rau lub hnub ci fais fab, muab kev ntseeg siab tsis sib haum xeeb thiab kev ua haujlwm hauv kev xa hluav taws xob. Ua nrog cov khoom siv siab heev, cov kab no muaj qhov tshwj xeeb ua haujlwm ntev, ua kom muaj kev ua haujlwm ntev txawm tias nyob hauv qhov chaw xav tau tshaj plaws. Nws txoj kev tsim kho kom yooj yim seamless zog hloov, optimizing hnub ci zog siv thiab maximizing system efficiency.
Daim ntawv pov thawj
PV07AC-F hnub ci cable yog UL (Underwriters Laboratories, Inc.) thiab TUV (German Technical Inspection Association) tau lees paub, ua kom lawv ua tau raws li kev nyab xeeb thoob ntiaj teb thiab cov qauv kev ua haujlwm. UL daim ntawv pov thawj yog ib qho kev lees paub tias cov cables ua tau raws li qhov yuav tsum tau muaj kev nyab xeeb, ua rau lawv tsim nyog rau ntau yam kev siv hluav taws xob nrog kev ntseeg siab. TUV daim ntawv pov thawj yog tshwj xeeb tshaj yog rau cov tshuab hluav taws xob tauj dua tshiab xws li photovoltaic (hnub ci) kev teeb tsa. Nrog rau cov ntawv pov thawj no, PV07AC-F cables muab kev ruaj khov, kev rwb thaiv tsev zoo, thiab kev ua haujlwm zoo hauv qhov xav tau ib puag ncig.
Pob
Tuam txhab Taw Qhia
Greater Wire chaw tsim tshuaj paus lub Hoobkas tshaj lij cable muaj qhov chaw tsim khoom ntse thiab digital. Los ntawm seamless kev koom ua ke ntawm cov cuab yeej txiav-ntug, lub Hoobkas ua tiav tshem tawm qhov yuam kev thiab qhov tsis xws luag uas yuav tshwm sim hauv cov txheej txheem kev sib dhos ib txwm muaj. Kev hloov mus rau digital manufacturing tsis tsuas yog ua kom muaj txiaj ntsig zoo xwb tab sis kuj qhia peb txoj kev cog lus los muab peb cov neeg siv khoom nrog cov khoom muaj kev ntseeg siab tshaj plaws. Lub tuam txhab ntse lub hauv paus ua kom muaj cov txheej txheem ntau lawm thiab tsis muaj kev ua yuam kev, txo qhov muaj peev xwm ntawm tib neeg muaj feem cuam tshuam thiab nce qhov ua tsis tiav yav dhau los. Muaj tseeb thiab automated soj ntsuam mechanism, lub Hoobkas nruj me ntsis ua raws li kev tswj kom zoo. Cov khoom raug tshuaj xyuas zoo txij thaum pib mus rau theem kawg ntawm kev tsim khoom. Kev tshawb pom cov duab digital ntse thiab laser thev naus laus zis tau siv los xyuas kom meej tias txhua yam khoom ua tau raws li cov qauv nruj nruj los ntawm peb lub tuam txhab. Qhov kev cog lus rau kev ua tau zoo no txuas ntxiv mus rau peb qhov kev tshuaj xyuas qhov tseeb, nrog cov cuab yeej siv tshuab ua haujlwm tau ua tiav qhov tseeb ntawm 0.002 hli, tshaj qhov ntsuas kev lag luam.
cov neeg siv khoom
Greater Wire, raws li ib tug kws tshaj lij hlau thiab cable export chaw tsim tshuaj paus, muaj cov neeg muas zaub thoob plaws lub ntiaj teb no, thiab peb paub txog cov hlau thiab cable qauv ntawm txawv teb chaws. Peb tsis tsuas yog muaj cov neeg ua haujlwm thiab cov kws tshaj lij hluav taws xob hauv ntau lub tebchaws, tab sis kuj muaj pab pawg kws tshaj lij los muab kev txhawb nqa.
Tus khub
FAQ
Q: Koj puas yog lub tuam txhab lag luam lossis chaw tsim khoom?
Q: Koj puas tuaj yeem ua OEM thiab ODM?
Q: Peb puas tuaj yeem siv peb lub logo?
Cim npe nrov: pv07ac-f hnub ci cable, Tuam Tshoj pv07ac-f hnub ci cable manufacturers, lwm tus neeg, Hoobkas
| Tus neeg tsav tsheb hla ntu | Rwb thaiv tsev Thickness | Sheath Thickness | Cable OD | Tus neeg xyuas pib kuj | |
| mm2 ua | AWG | mm | mm | mm | Ω/km 20 degree |
| 3x1 | 18 | 0.8 | 0.74 | 5.00土0.2 | 20 |
| 3x1.5 | 16 | 0.8 | 0.88 | 5.00土0.2 | 13.7 |
| 3x2.5 | 14 | 0.8 | 1.02 | 7.25土0.2 | 8.27 |
| 3x4 | 12 | 0.8 | 1.16 | 9.65土0.2 | 5.09 |
| 3x6 | 10 | 0.8 | 1.32 | 13.75土0.5 | 3.39 |
| 3x10 | 8 | 0.8 | 1.60 | 22.40土0.5 | 1.95 |
| 3x16 | 6 | 0.8 | 1.99 | 35.80土0.5 | 1.24 |
