Silicone Tshuab Wiring Cable rau kev tiv thaiv sab hauv kev sib txuas

Kub cheeb tsam sab hauvxav tau ntau tshaj li lub npe cable paub; nws xav tau kev tsim kho kom haum rau thermal load, enclosure tsim thiab kev pabcuam. Cov khoom siv hluav taws xob tiv thaiv hluav taws xob no yog tsim los rau ib qho -cov tub ntxhais sib txuas hauv cov tshuab tiv thaiv, suav nrog cov tsev txhab nyiaj siv hluav taws xob, ntsuas kub, teeb, sensors thiab lub davhlau ya nyob twg. Silicone tseem yoog raws ntau qhov kub thiab txias, tab sis nws yuav tsum tau tiv thaiv los ntawm kev puas tsuaj thiab yuav tsum tsis txhob xav tias tsim nyog rau kev sib tw los yog kev mus ncig tsis tau. GERITEL WIRE pab cov neeg tsim khoom xaiv cov khoom siv silicone hlau nrog cov qauv tsim nyog thiab cov ntaub ntawv. Validate tam sim no nqa peev xwm, routing, txiav, nplaim kev ua tau zoo thiab hauv zos ua raws li ib feem ntawm lub tiav tshuab kev soj ntsuam.

PRODUCT SPECIFICATIONS

low corrosive gas silicone equipment wire

Daim ntawv thov

Tsim los siv rau hauv ib puag ncig uas yuav tsum tau ua kom muaj cua sov, SIA thiab SIAF cables muaj cov khoom siv hluav taws xob kub txog li 200℃thiab tuaj yeem ua haujlwm ntawm qhov kub thiab txias li -60 degree. Cov cables no yog cov pa luam yeeb tsawg xoom halogen thiab tsim nyog rau cov chaw tsim hluav taws xob, ntau yam kev lag luam hauv kev ua, ntim khoom, tub yees, cov chaw tsim khoom, kev tsim kho huab cua thiab nkoj tsim.

SPECIFICATIONS
Kev ntsuas voltage Uo / U	SIA: 300/500V SIAF: 0.25mm² txog 6mm² 300/500V; 10mm² thiab siab dua: 0.6 / 1kV
Kev ntsuas kub	Tsau: -60℃rau +200 degree
Yam tsawg kawg Bending Radius	Tsau: 4 x tag nrho txoj kab uas hla
Tus coj	Chav Kawm 1 khoom tooj liab (dawb lossis tinned) tus neeg xyuas pib Chav Kawm 5 hloov tau tooj liab (dawb lossis tinned) tus neeg xyuas pib
Rwb thaiv tsev	Silicone roj hmab
Sheath Xim	Dub, Xiav, Xim av, Liab, Dawb, Grey, Paj yeeb, Daj, Ntsuab / Daj, Txiv kab ntxwv, Violet
Cov qauv	TS EN 50525-2-41, IEC / EN 60228

DIMENSION

Cov tub ntxhais Silicone Rubber Insulated Cable (SIA)

NO.OF CORE

	NOMINAL CROSS SECTIONAL AREA mm² os	NOMINAL THICKNESS NTAWM INSULATION mm² os	NOMINAL ZAUM DIAMETER mm² os	NOMINAL LUB SIJ HAWM kg/km
	NOMINAL CROSS SECTIONAL AREA mm² os	NOMINAL THICKNESS NTAWM INSULATION mm² os	NOMINAL ZAUM DIAMETER mm² os	NOMINAL LUB SIJ HAWM kg/km
1	0.5	0.6	2.0	10
1	0.75	0.6	2.2	12
1	1	0.6	2.3	15
1	1.5	0.6	2.6	20
1	2.5	0.7	3.2	31
1	4	0.8	3.9	48
1	6	0.8	4.4	67
1	10	1	5.6	108

Flexible Core Silicone Rubber Insulated Cable (SIAF)

NO.OF CORE

	NOMINAL CROSS SECTIONAL AREA mm² os	NOMINAL THICKNESS NTAWM INSULATION mm² os	NOMINAL ZAUM DIAMETER mm² os	NOMINAL LUB SIJ HAWM kg/km
	NOMINAL CROSS SECTIONAL AREA mm² os	NOMINAL THICKNESS NTAWM INSULATION mm² os	NOMINAL ZAUM DIAMETER mm² os	NOMINAL LUB SIJ HAWM kg/km
1	0.25	0.6	1.8	7
1	0.35	0.6	1.9	8
1	0.5	0.6	2.1	10
1	0.75	0.6	2.3	13
1	1	0.6	2.5	15
1	1.5	0.6	2.8	21
1	2.5	0.7	3.5	34
1	4	0.8	4.1	49
1	6	0.8	4.7	68
1	10	1	6.1	110
1	16	1.2	7.5	168
1	25	1.4	9.1	254
1	35	1.4	10.3	347
1	50	1.6	12	490
1	70	1.8	13.7	686
1	95	1.8	15.6	888
1	120	1.8	17.4	1149
1	150	2	19.3	1411
1	185	2.2	21.4	1722
1	240	2.4	24.3	2284
1	300	2.6	26.9	2895

Cov kws qhia

Class 5 Flexible Copper Conductors rau Tib Tub Ntxhais thiab Ntau -Core Cables

NOMINAL CROSS SIBAL UA mm² os	MAXIMUM RESISTANCE CONDUCTOR ntawm 20 degree ohms/km
NOMINAL CROSS SIBAL UA mm² os	Circular, Annealed Copper Conductors, Hlau -Coated Wires
0.5	36.7
0.75	24.8
1	18.2
1.5	12.2
2.5	7.56
4	4.7
6	3.11
10	1.84

Class 5 Flexible Copper Conductors for Single Core thiab Multi-Core Cables (SIAF)

NOMINAL CROSS SIBAL UA mm² os	MAXIMUM DIAMETER NTAWM WIRES IN CONDUCTOR mm	MAXIMUM RESISTANCE CONDUCTOR ntawm 20 degree ohms/km
NOMINAL CROSS SIBAL UA mm² os	MAXIMUM DIAMETER NTAWM WIRES IN CONDUCTOR mm	Hlau -Coated Hlau
0.25	0.21	86
0.35	0.21	55.5
0.5	0.21	40.1
0.75	0.21	26.7
1	0.21	20
1.5	0.26	13.7
2.5	0.26	8.21
4	0.31	5.09
6	0.31	3.39
10	0.41	1.95
16	0.41	1.24
25	0.41	0.795
35	0.41	0.565
50	0.41	0.393
70	0.51	0.277
95	0.51	0.21
120	0.51	0.164
150	0.51	0.132
185	0.51	0.108
240	0.51	0.0817
300	0.51	0.0654

TAM SIM NO YUAV TSUM TAU

Cov tub ntxhais Silicone Rubber Insulated Cable (SIA)

NOMINAL CROSSS ECTIONAL AREA mm² os	TAM SIM NO RATING AIR Amps
NOMINAL CROSSS ECTIONAL AREA mm² os	ntawm 30 degree	ntawm 60 degree	ntawm 90 degree	ntawm 120 degree	ntawm 150 degree
0.5	24	21	17	14	9
0.75	30	26	22	17	11
1	36	31	26	20	13
1.5	45	39	33	26	17
2.5	61	53	45	55	23
4	81	71	60	47	31
6	105	92	77	60	39
10	146	128	107	84	55

Flexible Core Silicone Rubber Insulated Cable (SIAF)

NOMINAL CROSSS ECTIONAL AREA mm² os	TAM SIM NO RATING AIR Amps
NOMINAL CROSSS ECTIONAL AREA mm² os	ntawm 30 degree	ntawm 60 degree	ntawm 90 degree	ntawm 120 degree	ntawm 150 degree	ntawm 170 degree
0.25	15	13	11	9	6	3
0.35	19	17	14	11	7	4
0.5	23	20	17	13	9	5
0.75	30	26	22	17	11	6
1	35	31	26	20	13	7
1.5	44	38	32	25	17	8
2.5	61	53	45	35	23	12
4	82	71	60	47	31	16
6	104	91	77	60	39	20
10	148	129	108	85	56	28
16	197	173	145	114	75	58
25	263	230	193	151	99	51
35	327	286	240	188	124	63
50	413	362	304	238	157	80
70	531	465	391	306	201	103
95	623	545	458	359	236	121
120	738	645	543	425	280	143
150	850	744	626	491	323	166
185	969	848	714	560	369	190
240	1191	1043	879	689	454	234
300	1339	1173	988	776	512	264

CERTIFICATIONS

low corrosive gas single core silicone wire

Ntim

low corrosive gas silicone appliance wire

Yob

Yas Reel

Ntoo Ntoo Reel

APPLICATION

Muaj Machinery & Automation

Marine & Shipbuilding

Cov khoom siv tub yees & HVAC

CAS

Bosch Kev Lag Luam 4.0 Ntse Hoobkas

Liebherr Professional Refrigeration Systems upgrade

Mitsui E&S Marine Propulsion System

Vim li cas thiaj xaiv peb

30Xyoo ntawm kev paub
hauv ib qho - nres kev pabcuam

Dongguan Greater Wire & Cable Co., Ltd. yog tus kws tshaj lij engineering- qib cable chaw tsim khoom hauv Suav teb, muab cov ntawv pov thawj hluav taws xob cable daws teeb meem rau lub tsev, kev lag luam, tsuas, hluav taws xob, thiab kev tsim kho vaj tse thoob ntiaj teb.

Nrog rau 30,000 m² Hoobkas, 30 cov kab ntau lawm, cov kws tshaj lij engineers, thiab pab pawg tswj xyuas nruj, peb muab cov khoom lag luam txhim khu kev qha, traceable, thiab ua raws cov khoom siv cable rau kev siv engineering thoob ntiaj teb. Peb cov khoom tau txais kev txhawb nqa los ntawm cov ntawv pov thawj suav nrog SAA, UL, cUL, VDE, TÜV, CE, CB, IEC, BPS, thiab ISO.

Peb tau cog lus rau kev nyab xeeb, kev ua tau zoo, pob tshab, thiab kev sib koom ua ke ntev -. Los ntawm kev tshuaj xyuas cov khoom siv raw mus rau kev kuaj cov khoom tiav, txhua batch yog ua tib zoo tswj xyuas kom ruaj khov kev ua tau zoo thiab siv tau qhov project.

Greater Cable - Certified Quality. Kev ntseeg tau. Engineering tus nqi.

15K

Kev Ua Haujlwm tiav

150+

cov neeg ua haujlwm tshaj lij

15K

zoo siab cov neeg siv khoom

92+

khoom plig & certifacates

COV TSWV YIM

ozone resistant single core silicone wire

GLOBAL CERTIFICATIONS

weather resistant silicone cable

COV PHOOJ YWG

weather resistant SIAF cable

INTERNATIONL TRANSPORTATION

Hiav txwv Freight

Peb muab cov kev daws teeb meem hauv hiav txwv txhim khu kev qha rau loj - ntim xaj. Koj cov khoom tau ntim khoom ruaj ntseg thiab xa mus rau hauv cov thawv ntim khoom, xyuas kom tus nqi - xa mus rau cov chaw nres nkoj thoob ntiaj teb.

Cua Freight

Rau kev xa khoom sai, peb cov kev pabcuam huab cua ua kom koj cov khoom mus txog thoob ntiaj teb cov chaw sai sai, nrog kev ceev faj thiab taug qab tag nrho ntawm txoj kev.

International Express

Xav tau kev thauj mus los sai? Peb cov kev pabcuam nthuav qhia thoob ntiaj teb muab kev txiav txim me me mus rau nruab nrab kom tau txais txiaj ntsig zoo, muab lub qhov rooj - mus rau - qhov rooj pabcuam nrog - lub sijhawm taug qab kom muaj kev thaj yeeb nyab xeeb.

COOPERATIVE PARTNER

Peb tab tom nrhiav kev sib koom tes los nthuav peb txoj kev lag luam.

weather resistant high temperature cable

weather resistant silicone equipment wire

weather resistant single core silicone wire

weather resistant silicone appliance wire

moisture resistant high temperature cable

moisture resistant silicone equipment wire

moisture resistant single core silicone wire

Yuav koom tes nrog peb li cas?

Tsuas qhia koj cov kev xav tau, tau txais peb cov kev daws teeb meem, paub meej cov qauv, thiab txaus siab rau kev tsim khoom sai, txhim khu kev qha thiab xa khoom thoob ntiaj teb - ua haujlwm nrog peb yog qhov yooj yim.

Peb qhov chaw nyob

Building 2, No. 40 Luxi 2nd Road, Liaobu Town, Dongguan City, Guangdong Province, Suav teb

Xov tooj

+86 136 6257 9592

+86 135 1078 4550

E -mail

manager01@greaterwire.com

moisture resistant silicone appliance wire

FAQ

Dab tsi yog qhov ntsuas kub tsis tu ncua ntawm SIAF hlau?

SIAF qhov ntsuas kub tsis tu ncua feem ntau siv rau EN 50525-2-41 cov khoom lag luam nce mus txog 180℃hauv kev pabcuam ruaj khov, tab sis cov ntaub ntawv raug txiav txim siab. ambient kub, conductor cua sov thiab lub sij hawm raug yuav tsum tau muab xam tag nrho. Qhia tawm hom davhlau ya nyob twg, khoov cov xwm txheej thiab cov duab teeb tsa kom txo qis kev pheej hmoo xaiv. GERITEL WIRE tuaj yeem txhawb nqa cov qauv kev sim thiab ntau lawm nrog kev txheeb xyuas zoo ib yam, muab thermal thiab cov khoom engineers txoj kev pom zoo.

Puas tuaj yeem silicone hlau ua haujlwm tsis tu ncua ntawm 200 degree?

A 200℃silicone wire claim should not be applied automatically to every SIA/SIAF construction. Some silicone formulations reach that level, while harmonized SIAF products are often specified at 180℃; request exact test evidence. Practical support matters here: GERITEL WIRE offers technical clarification and practical sourcing support for thermal and product engineers, including document and sample coordination. Ask for a sample so stripping, crimping and heat-cycle trials can be completed.

Cov hlau puas tuaj yeem muaj sia nyob luv luv tshaj nws qhov kev ntsuas ib txwm?

Lub sij hawm luv luv high kub hlaukev ua tau zoo nyob ntawm qhov kub thiab txias, lub sijhawm, huab cua, kev ntxhov siab thiab kev tsim kho pom zoo. Kev mus ncig luv luv yuav tsum tau lees paub los ntawm cov chaw tsim khoom es tsis yog kev txiav txim siab los ntawm cov khoom siv silicone ib leeg. Rau thermal thiab khoom engineers, GERITEL WIRE tuaj yeem npaj cov ntaub ntawv soj ntsuam pom zoo thiab cov ntaub ntawv xa khoom txuas mus rau ntau lawm. Cov kauj ruam tom ntej yog qhov ua tau zoo: Pom zoo rau cov qauv kaw thiab cov ntaub ntawv kho dua ua ntej ntau lawm.

Puas yog silicone xaim tseem hloov tau hauv qab khov?

Tsis tshua muaj kub hloov tau yooj yim silicone cable muaj nuj nqis vim tias silicone tseem pliable zoo hauv qab qhov ntau ntawm PVC. Cov ntaub ntawv cov khoom lag luam yuav tsum tau hais txog qhov ntsuas kub qis qis, thaum cov ntsaws ruaj ruaj thiab cov terminals yuav tsum ua kom haum rau kev sib xyaw ua ke thiab kev caij tsheb kauj vab txias. GERITEL WIRE ua haujlwm los ntawm kev kos duab thiab kev ua haujlwm tau muab los ntawm cov khoom siv thermal thiab cov khoom lag luam, tsis yog los ntawm cov xov xwm kub kub. Thov daim ntawv qhia tseeb thiab cov ntaub ntawv pov thawj ua ntej pom zoo cov khoom.
