PRODUCT REAL SHOT
2/0 AWG UL 83 Stranded Copper THHN/THWN-2 Hlau rau Conduit
PRODUCT SPECIFICATIONS
|
Tus coj |
Tus coj Stranding |
Rwb thaiv tsev Thickness |
Jacket Thickness | Nominal O.D. |
Kwv yees li Net nyhav | Kev tso cai muaj peev xwm (1) @30℃Ambient |
|
| AWG/Kcmil | Number of Strands | mils | mils | Ntiv | lbs / 1000 ft | 75 degree | 90 degree |
| 14 | 1 | 15 | 4 | 0.101 | 17 | 20 | 25 |
| 12 | 1 | 15 | 4 | 0.119 | 25 | 25 | 30 |
| 10 | 1 | 20 | 4 | 0.150 | 39 | 35 | 40 |
| 14 | 19 | 15 | 4 | 0.113 | 16 | 20 | 25 |
| 12 | 19 | 15 | 4 | 0.133 | 25 | 25 | 30 |
| 10 | 19 | 20 | 4 | 0.164 | 39 | 35 | 40 |
| 8 | 19 | 30 | 5 | 0.218 | 63 | 50 | 55 |
| 6 | 19 | 30 | 5 | 0.252 | 96 | 65 | 75 |
| 4 | 19 | 40 | 6 | 0.325 | 153 | 85 | 95 |
| 3 | 19 | 40 | 6 | 0.353 | 193 | 100 | 115 |
| 2 | 19 | 40 | 6 | 0.381 | 236 | 115 | 130 |
| 1 | 19 | 50 | 7 | 0.437 | 300 | 130 | 145 |
| 1/0 | 19 | 50 | 7 | 0.480 | 373 | 150 | 170 |
| 2/0 | 19 | 50 | 7 | 0.522 | 464 | 170 | 195 |
| 3/0 | 19 | 50 | 7 | 0.572 | 577 | 200 | 225 |
| 4/0 | 19 | 50 | 7 | 0.629 | 719 | 230 | 260 |
| 250 | 37 | 60 | 8 | 0.703 | 857 | 255 | 290 |
| 300 | 37 | 60 | 8 | 0.758 | 1019 | 285 | 320 |
| 350 | 37 | 60 | 8 | 0.808 | 1181 | 310 | 350 |
| 400 | 37 | 60 | 8 | 0.851 | 1342 | 335 | 380 |
| 500 | 37 | 60 | 8 | 0.937 | 1665 | 380 | 430 |
| 600 | 61 | 70 | 9 | 1.036 | 2002 | 420 | 475 |
| 750 | 61 | 70 | 9 | 1.134 | 2465 | 475 | 535 |
| 1000 | 61 | 70 | 9 | 1.273 | 3296 | 545 | 615 |
CERTIFICATIONS
Ntim
Yas Reel
Ntoo Ntoo Reel
Loj Ntoo Reel
APPLICATION
CAS
Mayo Clinic Tsev Kho Mob, Saint Marys Campus
30 Hudson Yards
Stanford University California Asmeskas
Vim li cas thiaj xaiv peb
hauv ib qho - nres kev pabcuam
Dongguan Greater Wire & Cable Co., Ltd. yog tus kws tshaj lij engineering- qib cable chaw tsim khoom hauv Suav teb, muab cov ntawv pov thawj hluav taws xob cable daws teeb meem rau lub tsev, kev lag luam, tsuas, hluav taws xob, thiab kev tsim kho vaj tse thoob ntiaj teb.
Nrog rau 30,000 m² Hoobkas, 30 cov kab ntau lawm, cov kws tshaj lij engineers, thiab pab pawg tswj xyuas nruj, peb muab cov khoom lag luam txhim khu kev qha, traceable, thiab ua raws cov khoom siv cable rau kev siv engineering thoob ntiaj teb. Peb cov khoom tau txais kev txhawb nqa los ntawm cov ntawv pov thawj suav nrog SAA, UL, cUL, VDE, TÜV, CE, CB, IEC, BPS, thiab ISO.
Peb tau cog lus rau kev nyab xeeb, kev ua tau zoo, pob tshab, thiab kev sib koom ua ke ntev -. Los ntawm kev tshuaj xyuas cov khoom siv raw mus rau kev kuaj cov khoom tiav, txhua batch yog ua tib zoo tswj xyuas kom ruaj khov kev ua tau zoo thiab siv tau qhov project.
Greater Cable - Certified Quality. Kev ntseeg tau. Engineering tus nqi.
