Tus neeg xyuas pib:Flexible Bare annealed tooj liab
-
Rwb thaiv tsev;PVC
-
Voltage: 450/750V
-
Ua haujlwm kub:-10 degree rau 70 degree
Daim ntawv thov
PVC roj teeb welding cable yog ib lub cable tsim rau photovoltaic fais fab mov tshuab. Nws yog qhov tsim nyog rau qhov chaw ruaj khov hauv tsev thiab sab nraum zoov thiab tuaj yeem siv rau hauv cov kav dej lossis cov tshuab. Cov cable no yog ua los ntawm cov khoom siv PVC zoo, muaj huab cua zoo heev thiab tiv thaiv corrosion, thiab tuaj yeem tiv taus lub hnub ntev, los nag thiab lwm yam huab cua hnyav. Nws zoo heev rwb thaiv tsev kev ua tau zoo thiab hluav taws xob conductivity ua rau nws ib tug indispensable thiab tseem ceeb ib feem ntawm lub roj teeb pob welding, photovoltaic cell module kev twb kev txuas thiab fais fab kis systems. Tsis tas li ntawd, qhov yooj thiab kev ntseeg siab ntawm PVC roj teeb welding cable ua rau nws muab kev sib txuas hluav taws xob ruaj khov hauv qhov chaw ua haujlwm nyuaj, ua kom lub zog ua haujlwm tau zoo.
Feature
PVC roj teeb welding cable siv tau yooj yim liab qab tooj liab conductors, uas muaj zoo heev hluav taws xob conductivity thiab saj zawg zog, thiab yog haum rau vuam daim ntaub ntawv uas yuav tsum tau high tam sim no kis tau tus mob. Nws cov txheej txheej rwb thaiv tsev yog ua los ntawm cov khoom siv PVC, uas muaj cov cua kub zoo thiab corrosion kuj.
Daim ntawv pov thawj
Peb cov khoom tau dhau UL, SAA, TUV, VDE, CE, CB thiab lwm yam ntawv pov thawj. Peb lub tuam txhab muaj cov ntawv pov thawj zoo rau txhua cheeb tsam. Peb muaj ntau tshaj li 10 xyoo ntawm kev paub nyob rau hauv kev lag luam tawm txawv teb chaws, exporting rau ntau tshaj 90 lub teb chaws nyob ib ncig ntawm lub ntiaj teb no, thiab paub txog cov hlau thiab cable specifications thiab cov qauv ntawm ntau lub teb chaws.
Pob
Hoobkas
Dongguan Greater Wire & Cable Co., Ltd. yog tsim nyob rau hauv 1995, nws yog ib tug kws tshaj lij hlau thiab cable chaw tsim tshuaj paus. Peb lub tuam txhab muaj cov cuab yeej siv ntau lawm thiab cov cuab yeej tsim khoom, ua tiav cov khoom siv, thiab cov khoom siv tshuab muaj zog. Tom qab xyoo ntawm kev ua haujlwm hnyav thiab kev txhawb nqa ntawm cov neeg siv khoom los ntawm thoob plaws lub ntiaj teb, peb lub tuam txhab tau tsim kho sai thiab yeej muaj kev hwm thiab koom nrog kev lag luam txawv teb chaws. Lub tuam txhab tau dhau ls09001 kev tswj hwm kev ua haujlwm tau ntawv pov thawj, National high tech enterprise certification, national specialization, and special new enterprise certification.
Case
Tus khub
FAQ
Q: Koj puas yog cov chaw tsim khoom lossis tuam txhab lag luam?
Q: Thaum twg kuv tuaj yeem tau txais tus nqi?
Cim npe nrov: Tuam Tshoj pvc roj teeb welding cable manufacturers, lwm tus neeg, Hoobkas
| Tsim (no xmm2) |
Kwv yees li Conductor (mm) | Qhov nruab nrab rwb thaiv tsev Thickness (mm) | Max. Sab nraud (mm) |
Max. hluav taws xob tsis kam ntawm 20 degree (Ω / km) | Kwv yees qhov hnyav (KG / KM) | Kev ntsuas tam sim no hauv cov yeeb nkab hauv huab cua ntawm 30 degree (A) |
| 1x1.5 | 1.5 | 0.7 | 3.4 | 13.3 | 20 | 16 |
| 1x2.5 | 2.0 | 0.8 | 4.1 | 7.98 | 31 | 20 |
| 1x4 | 2.5 | 0.8 | 4.8 | 4.95 | 45 | 25 |
| 1x6 | 3.0 | 0.8 | 5.3 | 3.30 | 65 | 36 |
| 1x10 | 4.0 | 1.0 | 6.8 | 1.91 | 109 | 50 |
| 1x16 | 5.0 | 1.0 | 8.1 | 1.21 | 163 | 68 |
| 1x25 | 6.2 | 1.2 | 10.2 | 0.780 | 251 | 89 |
| 1x35 | 7.4 | 1.2 | 11.7 | 0.554 | 347 | 110 |
| 1x50 | 8.9 | 1.4 | 13.9 | 0.386 | 493 | 134 |
| 1x70 | 10.5 | 1.4 | 16.0 | 0.272 | 680 | 171 |
| 1x95 | 12.2 | 1.6 | 18.2 | 0.206 | 910 | 207 |
| 1x120 | 13.8 | 1.6 | 20.2 | 0.161 | 1140 | 239 |
| 1x150 | 15.4 | 1.8 | 22.5 | 0.129 | 1420 | 275 |
| 1x180 | 16.9 | 2.0 | 24.9 | 0.106 | 1730 | 314 |
| 1x240 | 19.5 | 2.2 | 28.4 | 0.0801 | 2270 | 369 |
